AS608 Optical Fingerprint Sensor Module
Original price was: ₵250.00.₵220.00Current price is: ₵220.00.
This is the AS608 Optical Fingerprint Sensor Fingerprint Module.
The fingerprint algorithm extracts features from the acquired fingerprint image and represents the fingerprint information. The storage, comparison, and search of fingerprints are all done by operating the fingerprint features.
Fingerprint processing includes two processes: the fingerprint registration process and the fingerprint matching process (in which fingerprint matching is divided into fingerprint comparison (1:1) and fingerprint search (1:N) two ways).
When the fingerprint is registered, two fingerprints are entered for each fingerprint, and the input image is processed twice. The synthesis module is stored in the module.
When the fingerprint is matched, the fingerprint sensor is used to input the fingerprint image to be verified and processed, and then it is compared with the fingerprint module in the module (if it is matched with a module specified in the module, it is called fingerprint comparison mode, ie, 1:1 mode. If matching with multiple modules is called fingerprint search, ie 1:N mode, the module gives the matching result (pass or fail).
Low power consumption, low cost, small size, excellent performance, Professional optical technology, precise module manufacturing techniques. Good image processing capabilities can successfully capture an image up to a resolution of 500 dpi Finger detection function.
Out of stock
Technical Details
- Item Type: Scanner
- R307S supports up to 162 fingerprints
- Model Type: Fingerprint Scanner
- Resolution: 500dpi
- Supply Current: <60mA
- Supply Voltage: 3.3V
- Peak Current: <60mA
- Window Area: 15.3×18.2mm
- Communication Mode: USB/UART
- Dimensions: 46×21×24mm
- Weight: 20g
Features
- Integrated image collecting and algorithm chip together, ALL-in-One.
- The fingerprint reader can conduct secondary development and can be embedded into a variety of end products.
- Low power consumption, low cost, small size, excellent performance.
- Resolution: 500dpi
- Fingerprint image entry time: <1.0 seconds
- Window area: 15.3×18.2MM
- Communication Interface: USB/UART
Applications :
- Biometric Security: Used in access control systems
- Attendance Systems: Ideal for employee/student tracking
- Smart Locks: Enhances security in doors and safes
- Embedded Systems: Integrates with microcontrollers and IoT devices
- Banking & Payment: Secures authentication in financial applications
- Personal Identification: Used for ID verification and authentication
Pin Out
Physical Attributes
- Dimensions: 46×21×24mm
- Weight (gm): 18
Package Includes
- 1 x AS608 Optical Fingerprint Sensor Fingerprint Module
- 1 x Connecting Cable (8-pin).
