16X2 Character Lcd Display
₵25.00
The LCD1602 Parallel LCD Display is an excellent choice for adding a simple and cost-effective 16×2 character display to your Arduino or microcontroller projects. It features white text on a Yellow backlight, offering high contrast and clear readability. The display is capable of showing up to 16 characters per line across 2 lines, making it suitable for presenting both text and numerical data, such as sensor readings (e.g., temperature or pressure) or operational status. This display is commonly used in Arduino-based projects and is easy to interface with, though it requires up to 8 digital pins for standard parallel communication. To overcome this limitation, an I2C adapter can be used, significantly reducing pin usage to just two I2C lines, and simplifying the wiring and coding process. For even greater convenience, pre-assembled I2C-enabled LCD1602 modules are available. This LCD module is ideal for various applications, including DIY electronics, sensor data monitoring, and embedded systems, providing a versatile and user-friendly visual output solution.
1 in stock
Features:
Compact Display: Displays 16 characters per line across 2 rows, providing enough space for essential data and messages.
Yellow Backlight: The bright yellow backlight improves visibility and adds a stylish look to your projects.
Wide Compatibility: Fully compatible with popular platforms such as Arduino, Raspberry Pi, and various microcontrollers.
Easy Integration: Equipped with a standard 16-pin interface for hassle-free wiring and setup.
Low Power Consumption: Energy-efficient design makes it ideal for battery-powered and portable applications.
Durable Design: Made from high-quality materials to ensure long-lasting performance and reliability.
Applications:
DIY electronics and hobbyist projects
Embedded systems and IoT devices
Industrial and home automation displays
Educational and prototype development
Technical Details
- Model Type: Other LCD
- Version Type: Affordable Version
- LCD Type: Character LCD module
- Model No.: LCD1602
- Backlight Color: Yellow
- Characters: 16
- Character Color: Black
- Input Voltage (V): 5
- Length (mm): 80
- Width (mm): 36
- Height (mm): 10
- Weight (g): 30
- Board Dimensions (LxWxH): 80 x 36 x 10 mm
Features
- 16 characters wide, 2 rows
- White text on a Yellow background
- Single LED backlight included, dimmable with a resistor or PWM
- Fully controllable with only 6 digital lines (any analog/digital pins can be used)
Drawing
Physical Attributes of 1602 lcd display
- Length (mm): 80
- Width (mm): 36
- Height (mm): 10
- Weight (g): 30
- Board Dimensions (LxWxH): 80 x 36 x 10 mm
Package Includes
- 1 x 16X2 1602 LCD1602 Character LCD Display Yellow Color
